2025 Ford Transit Interior


Whether you’re hauling cargo to the job site or passengers to their next destination, it’s hard to beat the expansive space of the latest Ford Transit. Boasting several wheelbase lengths, roof heights, and amenities, the 2025 Ford Transit Van provides the interior customization you need for your Rogers business or lifestyle. Learn more about the Ford Transit cargo dimensions, seating options, and interior accessories with this guide from Cornerstone Ford.


2025 Ford Transit Van Seating Dimensions

The 2025 Ford Transit lineup offers two distinct configurations: the Ford Transit Cargo Van and the Ford Transit Passenger Van. While both share many of the same roof heights and wheelbase options, they differ significantly in terms of seating capacity.

The Ford Transit Cargo Van, designed primarily for Coon Rapids businesses and upfitters, offers seating for only two in the front cab, leaving the rear open for cargo and tools. The Ford Transit Passenger Van, meanwhile, focuses on transporting people, filling the rear compartment with several rows of seats to accommodate group travel. See the differences between the Ford Transit Van seating capacities and dimensions in detail below:

2025 Ford Transit Cargo Van Interior Dimensions

Regular Wheelbase/Low Roof:

• Seating Capacity: 2 passengers
• Headroom: 40.8 inches
• Shoulder Room: 67.9 inches
• Hip Room: 60.7 inches
• Legroom (Min/Max): 39.7 inches / 41.3 inches

Regular Wheelbase/Medium Roof:

• Seating Capacity: 2 passengers
• Headroom: 52 inches
• Shoulder Room: 67.9 inches
• Hip Room: 60.7 inches
• Legroom (Min/Max): 39.7 inches / 41.3 inches

Long Wheelbase/Low Roof:

• Seating Capacity: 2 passengers
• Headroom: 40.8 inches
• Shoulder Room: 67.9 inches
• Hip Room: 60.7 inches
• Legroom (Min/Max): 39.7 inches / 41.3 inches

Long Wheelbase/Medium Roof:

• Seating Capacity: 2 passengers
• Headroom: 52 inches
• Shoulder Room: 67.9 inches
• Hip Room: 60.7 inches
• Legroom (Min/Max): 39.7 inches / 41.3 inches

Long Wheelbase/High Roof:

• Seating Capacity: 2 passengers
• Headroom: 56.6 inches
• Shoulder Room: 67.9 inches
• Hip Room: 60.7 inches
• Legroom (Min/Max): 39.7 inches / 41.3 inches

Long-EL Wheelbase/High Roof:

• Seating Capacity: 2 passengers
• Headroom: 56.6 inches
• Shoulder Room: 67.9 inches
• Hip Room: 60.7 inches
• Legroom (Min/Max): 39.7 inches / 41.3 inches

2025 Ford Transit Passenger Van Interior Dimensions

Long Wheelbase/Low Roof:

• Seating Capacity: 2, 12, or 15 passengers
• Headroom (1st/2nd/3rd/4th/5th Rows): 40.8 inches / 41.1 inches / 40.6 inches / 38.7 inches / 38.1 inches
• Shoulder Room (1st/2nd/3rd/4th/5th Rows): 67.9 inches / 71.4 inches / 67 inches / 67.8 inches / 67.8 inches
• Hip Room (1st/2nd/3rd/4th/5th Rows): 60.7 inches / 69.6 inches / 67.3 inches / 68 inches / 68 inches
• Legroom (1st/2nd/3rd/4th/5th Rows): 41.3 inches / 33.7 inches / 35.6 inches / 35.6 inches / 35.6 inches

Long Wheelbase/Medium Roof:

• Seating Capacity: 2, 12, or 15 passengers
• Headroom (1st/2nd/3rd/4th/5th Rows): 52 inches / 55.8 inches / 55.8 inches / 55.8 inches / 52.6 inches
• Shoulder Room (1st/2nd/3rd/4th/5th Rows): 67.9 inches / 71.4 inches / 67 inches / 67.8 inches / 67.8 inches
• Hip Room (1st/2nd/3rd/4th/5th Rows): 60.7 inches / 69.6 inches / 67.3 inches / 68 inches / 68 inches
• Legroom (1st/2nd/3rd/4th/5th Rows): 41.3 inches / 33.7 inches / 35.6 inches / 35.6 inches / 35.6 inches

Long Wheelbase/High Roof:

• Seating Capacity: 2, 12, or 15 passengers
• Headroom (1st/2nd/3rd/4th/5th Rows): 56.6 inches / 65.2 inches / 65.2 inches / 65.2 inches / 61.3 inches
• Shoulder Room (1st/2nd/3rd/4th/5th Rows): 67.9 inches / 71.4 inches / 67 inches / 67.8 inches / 67.8 inches
• Hip Room (1st/2nd/3rd/4th/5th Rows): 60.7 inches / 69.6 inches / 67.3 inches / 68 inches / 68 inches
• Legroom (1st/2nd/3rd/4th/5th Rows): 41.3 inches / 33.7 inches / 35.6 inches / 35.6 inches / 35.6 inches

Long-EL Wheelbase/High Roof:

• Seating Capacity: 2, 12, or 15 passengers
• Headroom (1st/2nd/3rd/4th/5th Rows): 56.6 inches / 65.2 inches / 65.2 inches / 65.2 inches / 61.3 inches
• Shoulder Room (1st/2nd/3rd/4th/5th Rows): 67.9 inches / 71.4 inches / 67 inches / 67.8 inches / 67.8 inches
• Hip Room (1st/2nd/3rd/4th/5th Rows): 60.7 inches / 69.6 inches / 67.3 inches / 68 inches / 68 inches
• Legroom (1st/2nd/3rd/4th/5th Rows): 41.3 inches / 33.7 inches / 35.6 inches / 35.6 inches / 35.6 inches

2025 Ford Transit Cargo Dimensions

While the Ford Passenger Van excels in seating and comfort, the Ford Transit Cargo Van interior offers superior cargo space for all your gear. See the Ford Transit cargo dimensions for each model below to determine which has the carrying capacity you need for your Anoka travels:

2025 Ford Transit Cargo Van Interior Dimensions

Regular Wheelbase/Low Roof:

• Cargo Length Front (At Floor/At Belt): 126 inches / 115.9 inches
• Cargo Width Between Wheelhouse: 54.8 inches
• Cargo Height Maximum: 56.9 inches
• Cargo Volume (Behind First Row/Maximum): 246.7 cubic feet / 280.9 cubic feet

Regular Wheelbase/Medium Roof:

• Cargo Length Front (At Floor/At Belt): 126 inches / 115.9 inches
• Cargo Width Between Wheelhouse: 54.8 inches
• Cargo Height Maximum: 72 inches
• Cargo Volume (Behind First Row/Maximum): 315.2 cubic feet / 358.7 cubic feet

Long Wheelbase/Low Roof:

• Cargo Length Front (At Floor/At Belt): 143.7 inches / 133.6 inches
• Cargo Width Between Wheelhouse: 54.8 inches
• Cargo Height Maximum: 56.9 inches
• Cargo Volume (Behind First Row/Maximum): 277.7 cubic feet / 311.9 cubic feet

Long Wheelbase/Medium Roof:

• Cargo Length Front (At Floor/At Belt): 143.7 inches / 133.6 inches
• Cargo Width Between Wheelhouse: 54.8 inches
• Cargo Height Maximum: 72 inches
• Cargo Volume (Behind First Row/Maximum): 357.1 cubic feet / 400.5 cubic feet

Long Wheelbase/High Roof:

• Cargo Length Front (At Floor/At Belt): 143.7 inches / 133.6 inches
• Cargo Width Between Wheelhouse: 54.8 inches
• Cargo Height Maximum: 81.5 inches
• Cargo Volume (Behind First Row/Maximum): 404.3 cubic feet / 453.4 cubic feet

Long-EL Wheelbase/High Roof:

• Cargo Length Front (At Floor/At Belt): 172.2 inches / 162 inches
• Cargo Width Between Wheelhouse (SRW/DRW): 54.8 inches / 45.4 inches
• Cargo Height Maximum: 81.5 inches
• Cargo Volume (Behind First Row/Maximum): 487.3 cubic feet / 536.4 cubic feet

2025 Ford Transit Passenger Van Interior Dimensions

Long Wheelbase/Low Roof:

• Cargo Length Front (At Floor/At Belt): 141.7 inches / 132.8 inches
• Cargo Width Between Wheelhouse: 53.7 inches
• Cargo Height Maximum: 52.8 inches
• Cargo Volume (Behind 1st/2nd/3rd/4th Rows): 223.5 cubic feet / 150 cubic feet / 91.5 cubic feet / 48.9 cubic feet

Long Wheelbase/Medium Roof:

• Cargo Length Front (At Floor/At Belt): 141.7 inches / 132.8 inches
• Cargo Width Between Wheelhouse: 53.7 inches
• Cargo Height Maximum: 67.6 inches
• Cargo Volume (Behind 1st/2nd/3rd/4th Rows): 303.1 cubic feet / 206.8 cubic feet / 133.9 cubic feet / 72.8 cubic feet

Long Wheelbase/High Roof:

• Cargo Length Front (At Floor/At Belt): 141.7 inches / 132.8 inches
• Cargo Width Between Wheelhouse: 53.7 inches
• Cargo Height Maximum: 77 inches
• Cargo Volume (Behind 1st/2nd/3rd/4th Rows): 349.6 cubic feet / 240.1 cubic feet / 157 cubic feet / 85.8 cubic feet

Long-EL Wheelbase/High Roof:

• Cargo Length Front (At Floor/At Belt): 170.2 inches / 161.3 inches
• Cargo Width Between Wheelhouse: 53.7 inches
• Cargo Height Maximum: 77 inches
• Cargo Volume (Behind 1st/2nd/3rd/4th/5th Rows): 425.4 cubic feet / 313.1 cubic feet / 230 cubic feet / 184 cubic feet / 100.5 cubic feet

2025 Ford Transit Interior Accessories & Features

Once you’ve explored the Ford Transit Van seating and cargo dimensions, you’re ready to experience all the cutting-edge convenience and connectivity amenities this unique van has to offer. With available features like a SYNC® 4 infotainment system and Ford Pro™ Telematics, the driver-focused Ford Transit Van interior provides everything you need for a connected Otsego journey.

And, if you’d like to upgrade your experience, you’ll find plenty of manufacturer-recommended Ford Transit interior accessories at Cornerstone Ford’s parts department. Some available Ford Transit interior accessories include:

• Heavy-duty cargo flooring
• Fixed, multi-level shelving
• All-weather floor mats
• Auxiliary fuse panel with high-spec interface connector
• Vehicle maintenance monitor
• Power outlets (110V/400W)
• D-Pillar assist handles
• Full rear compartment lighting
• And more!
